WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM

Basic Information
Place of Origin: Sichuan, CHINA
Brand Name: IOTROUTER
Certification: CE FCC RoHs
Model Number: EG8000mini
Minimum Order Quantity: 1PCS
Price: USD99~199/PCS
Packaging Details: 270*180*6mm CARTON PACKAGE
Delivery Time: 1 WEEK
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/MONTH
Material: Galvanized Steel Sheet Interface: RS485/RS232/2USB
Protocol: BACnet CPU: ARM Cortex-A72 4*1.5G
Storage: 1G + 8G Operating Temperature: -20~80℃
Storage Temperature: -20~85℃ Environment Humidity: 10-90%RH (non-condensing)
Cooling Method: Heat Sink / Dissipation Silicone

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM





Parameters of Edge Computing Gateway





Hardware
DO
4*Relay Output (10A/250VAC 30VDC)
DI
4*Relay Input (Wet&Dry nodes)
AO
4*Analog Output (4-20mA, 12-bit precision)
AI
4*Analog Input (4-20mA, 12-bit precision)
LED
Support DO/DI status indication (customizable)





Software parameters
Ops
Support remote configuration/upgrade/management
VPN
Support intranet penetration support PLC remote upload and download (network port)
Edge Computing
Support drag and drop programming
Support zero-code development
Support JavaScript development
Data Storage
Support TSDB(Time Series Databases)
Industrial Agreement
Support multiple industrial protocols (Developing)
Network Protocol
MQTT/HTTP/TCP/UDP/WEBSOCKET





Edge8000 series products are edge computing gateways launched by IOTRouter Chengdu. With its rich hardware interfaces, drag-and-drop programming method, Zero Code design concept, convenient remote management and other characteristics, It can quickly, flexibly, accurately and efficiently respond to various IoT industry needs. Edge8000 abstracts complex hardware interfaces, different industrial network protocols, etc. into Nodesone by one.



Users can use these Nodes flexibly to replace the traditional complex and inefficient coding process by dragging and connecting. Really let customers focus on business logic and quickly create their own gateway equipment. The mission of Edge8000 is to continuously develop new Nodes to serve industry customers to adapt to the fragmentation of IoT industry needs.





Cortex-A72 Quad-Core processor give the gateway powerful edge computing capabilities to perform data optimization, real-time response, agile connection, smart applications, security and privacy protection at the IoT edge, and effectively reduce the workload of cloud-end computing.







From processor chip, memory chip to communication module and power supply terminal, the product adopts strict industrial grade standards. Meeting industrial grade on indexes including EMC grade 3, wide operating temperatures, the gateway is solid and durable to withstand the harsh environmental conditions of industrial sites.







WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 0

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 1



WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 2

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 3





WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 4

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 5

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 6

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 7

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 8

WAN/LAN Switching Selection Edge Computing Gateway RS485 Serial Router For Alarm System Support OEM ODM 9
